R6L Patroller

Lightweight Multi-Purpose Helmet

The R6L Patroller is a lightweight helmet which can be configured for a wide range of uses from Industrial to Wildland Firefighting. With it’s military styling, the Patroller has been designed to accommodate tactical Picatinny Rails and VAS shroud for attaching extra equipment such as cameras, earmuffs, torch, night vision goggles, and face protection. It has a larger shell than the other R6 Series helmets, which also makes it a great choice for larger head sizes due to the increased internal space. The Patroller can also be configured like a standard Pacific Helmet with features such as external clip-on face shield. The Patroller was awarded a Gold at the New Zealand Best Design Awards in 2016. Please note: the R6L Patroller was previously called the R6R.

Recommended Uses

The R6L Patroller can be configured for the following uses:

Wildland Firefighting

Wildland Firefighting
AS/NZS 1801:1997 Type 3, or EN 16471:2014

USAR, Paramedic, & Rescue

USAR, Paramedic, & Rescue
NFPA 1951:2020, AS/NZS 1801:1997 Type 2, or EN 16473:2014

Industrial Safety

Industrial Safety
AS/NZS 1801:1997 Type 1 & 2, EN 397:2012, OR ANSI Z89.1:2014 (COMPLIANT)

Please note: helmets pictured may be shown with optional features. Please ask your Pacific Helmets representative for more information.

Features of the R6L Patroller

Note: Feature Compatibilities

Some features may be either compulsory or unavailable depending on the standard selected. Please ask your Pacific Helmets representative for more information on feature compatibilities.

Included Features

Provides integral strength and excellent penetration protection. This lightweight shell is chemical and UV resistant with inherent heat and flame resistance. Expected service life of 15+ years with proper care and maintenance.

Size 52–65cm (downsizing adjustment kits and XL sizes available). Simple operation with a single gloved hand. Comes with comfortable front and rear sweat padding in leather and is easily removable and replaceable for decontamination.

Single handed adjustment at multiple locations for maximum comfort and stability. Chin cup or chin loop optional (standard dependent).

Can be easily secured, released, and adjusted with a gloved hand.

Fully modular for easy decontamination and replacement without special tools.

For mounting accessories such as Night Vision Goggles, Cameras, Lamps.

For mounting accessories such as torches.

Available in Clear or Smoke Tint.

For mounting either a UK3AA or Adaro Adalit L5 torch (requires torch clip).

Choose from Goggle Posts, Rear Rubber Straps, or Rear Polyester Straps.

Choose from 4pt Front Bungy or Front Rubber Straps.

Allow helmet to drain water efficiently.

Choose from 25mm or 30mm.

Choose from Black Nomex®, Blue, Orange or Yellow FR Cotton.

Allows the helmet to be stored on a hook when not in use.

Premium 3M™ 680 or 3M™ 8887 Reflective Trims available in a range of colours.

Customised branding, rank markings, or other decals are available by request.

Specifications

Sizing

Headband adjusts between 52-65cm. Downsize Kit or Extra Large Headband are also available for smaller or larger head sizes.

Colours Available

Our range of standard colours can be seen here. Custom colours also available, MOQ may apply.

Certification

Helmet is certified to the following standards:

AS/NZS 1801:1997 Type 1 & 2 Industrial
AS/NZS 1801:1997 Type 2 Technical Rescue
AS/NZS 1801:1997 Type 3 Wildland Firefighting
EN 16471:2014 (CE & UKCA) Wildland Firefighting
EN 16473:2014 (CE & UKCA) Technical Rescue
NFPA 1951:2020 Technical Rescue

Eye Protector certified to the following standards:

ANSI Z87.1:2020
EN 166:2001

Configuration dependent on certification.

Warranty

Parts are covered for manufacturing defects and vary from 1-6 years for different helmet components. See the User Information Guide for more information.

Care

All parts can be removed with simple tools to enable your helmet to be cleaned and maintained. See the User Information Guide for more information.

Accessories

The F10 MkIII is compatible with lighting solutions such as the Underwater Kinetics eLED and Adaro Adalit L5 Torches, and can be fitted with Titan Firecomms with helmet mounted boom microphone and speaker systems. Some accessories may require selected helmet features.
