R3V4

Compact Multi-Purpose Helmet

The R3v4 Kiwi has a well proven pedigree as the go-to helmet for many USAR teams across the USA. The R3v4 features a fibreglass shell reinforced with DuPont™ Kevlar® and full cranium impact liner, essentially making it a compact version of a full structural firefighting helmet. It offers the ultimate level of safety in all possible situations. The R3v4 is also available, with some additional features, dual certified to NFPA 1971 and NFPA 1951. Note: Goggles not included.

Recommended Uses

USAR, Paramedic, & Rescue

USAR, Paramedic, & Rescue
NFPA 1951:2020

Structural Firefighting

Structural Firefighting
NFPA 1971:2018

Industrial Safety

Industrial Safety
ANSI Z89.1:2014 (COMPLIANT)

Please note: helmets pictured may be shown with optional features. Please ask your Pacific Helmets representative for more information.

Features of the R3v4

Note: Feature Compatibilities

Some features may be either compulsory or unavailable depending on the standard selected. Please ask your Pacific Helmets representative for more information on feature compatibilities.

Included Features

Provides integral strength and excellent penetration protection. This lightweight shell is chemical and UV resistant with inherent heat and flame resistance. Expected service life of 15+ years with proper care and maintenance.

Excellent thermal barrier. Unique crumple zone for superior shock absorption and internal air circulation

Flame retardant chinstrap come with Nexus Wideguard buckle.

Available in Clear or Smoke Tint. Choose from Manual operation with pull tabs or the One Touch Eye Protector™.

Size 52–65cm (downsizing adjustment kits and XL sizes available). Simple operation with a single gloved hand. Comes with comfortable front and rear sweat padding in leather and is easily removable and replaceable for decontamination.

Can be easily secured, released, and adjusted with a gloved hand.

Fully modular for easy decontamination and replacement without special tools.

Choose from Black Nomex®, Blue, Orange or Yellow FR Cotton.

Premium 3M™ 680 or 3M™ 8887 Reflective Trims available in a range of colours.

Customised branding, rank markings, or other decals are available by request.

Post mount for goggles (sold separately).

Specifications

Sizing

Headband adjusts between 52-65cm. Downsize Kit or Extra Large Headband are also available for smaller or larger head sizes.

Colours Available

Our range of standard colours can be seen here. Custom colours also available, MOQ may apply.

Certification

Helmet certified to the following standards:

NFPA 1971:2018 Structural Firefighting
NFPA 1951:2020 Technical Rescue
Compliant: ANSI Z89.1:2014 Industrial

Configuration dependent on certification.

Care

All parts can be removed with simple tools to enable your helmet to be cleaned and maintained. See the User Information Guide for more information.

Warranty

Parts are covered for manufacturing defects and vary from 1-6 years for different helmet components. See the User Information Guide for more information.

Accessories

The R3v4 Kiwi is compatible with lighting solutions such as the Underwater Kinetics eLED and Adaro Adalit L5 Torches, and can be fitted with Titan Firecomms with helmet mounted boom microphone and speaker systems. Some accessories may require selected helmet features.
