F11 Dragonfly

¾ Jet Style Structural Firefighting Helmet

The Pacific F11 offers a fresh take on structural fire helmet design. The F11 has been designed to maximise protection and practicality for the diverse range of duties modern Emergency Service personnel are called on to perform. Certified to AS/NZS4067:2012, NFPA 1971:2018 & NFPA 1951:2020, and EN443:2008 the F11 is a compact helmet ideal not only for structural firefighting but also for road crash rescue and confined space work. The compact design of the F11 makes it a truly multipurpose structural firefighting helmet.

The F11 features the DuPont™ Kevlar® and fibreglass reinforced composite shell, and full cranium protective polyurethane foam liner. That not only gives excellent impact and penetration protection but also deceleration impact and side impact protection that the AS/NZS4067:2012 standard requires.

As a complete safety platform the F11 offers boom microphone and speaker compatibility, an individualised fit, and a full range of face and hearing protection. Available with a 3 or 4-point chin strap the F11 features Pacific’s next generation headband with pivoting nape for enhanced comfort and secure fit to all head shapes and sizes. The face and hearing protection options include a full external face shield that is available in the customer’s preference of either a fixed hinge or clip-on hinge option, a unique “One Touch” automatically deployed internal eye protector, and clip-on hearing protection.

Recommended Uses

The F11 Dragonfly can be configured for the following uses:

Structural Firefighting

Structural Firefighting
AS/NZS 4067:2012, NFPA 1971:2018, or EN 443:2008

Please note: helmets pictured may be shown with optional features. Please ask your Pacific Helmets representative for more information.

Features of the F11

Note: Feature Compatibilities

Some features may be either compulsory or unavailable depending on the standard selected. Please ask your Pacific Helmets representative for more information on feature compatibilities.

Included Features

Provides integral strength and excellent penetration protection. This lightweight shell is chemical and UV resistant with inherent heat and flame resistance. Expected service life of 15+ years with proper care and maintenance.

Excellent thermal barrier. Unique crumple zone for superior shock absorption and internal air circulation

Size 52–65cm (downsizing adjustment kits and XL sizes available). Simple operation with a single gloved hand. Comes with comfortable front and rear sweat padding in leather and is easily removable and replaceable for decontamination.

Single handed adjustment at multiple locations for maximum comfort and stability. Leather cheek padding for added comfort (optional).

Can be easily secured, released, and adjusted with a gloved hand.

Fully modular for easy decontamination and replacement without special tools.

Available in Clear or Smoke Tint. Choose from Manual operation with pull tabs or the One Touch Eye Protector™.

Optional – Standard Dependent.
High speed particle protection. Heat and flame resistant. Anti-scratch and Antifog coated. Optically correct. Clip-On design allows the face shield to be removed when not in use.

For mounting either a UK3AA or Adaro Adalit L5 torch (requires torch clip).

Choose from 25mm or 30mm.

Choose from Black Nomex®, Blue, Orange or Yellow FR Cotton.

Allows the helmet to be stored on a hook when not in use.

Protective hood for giving extra protection to the helmet during high temperatures. Thermal Barrier for Hot Fire Training. *Compulsory for EN443:2008.

Premium 3M™ 680 or 3M™ 8887 Reflective Trims available in a range of colours.

Customised branding, rank markings, or other decals are available by request.

Specifications

Sizing

Headband adjusts between 52-65cm. Downsize Kit or Extra Large Headband are also available for smaller or larger head sizes.

Colours Available

Our range of standard colours can be seen here. Custom colours also available, MOQ may apply.

Care

All parts can be removed with simple tools to enable your helmet to be cleaned and maintained. See the User Information Guide for more information.

Certification

Helmet certified to the following standards:

AS/NZS 4067:2012 Structural Firefighting
EN 443:2008 Structural Firefighting *Aluminised Helmer Hood compulsory.
NFPA 1971:2018 Structural Firefighting

Face Shield is certified to the following standards:

AS/NZS 1337.1:2010
EN 14458:2004
NFPA 1971:2018

Eye Protector is certified to the following standards:

AS/NZS 1337.1:2010
ANSI Z87.1:2020
EN 166:2001
EN 14458:2004
NFPA 1971:2018

Configuration dependent on certification.

Warranty

Parts are covered for manufacturing defects and vary from 1-6 years for different helmet components. See the User Information Guide for more information.

Accessories

The F11 is compatible with lighting solutions such as the Underwater Kinetics eLED and Adaro Adalit L5 Torches, and can be fitted with Titan Firecomms with helmet mounted boom microphone and speaker systems. Some accessories may require selected helmet features.
