F10 MkV

Jet Style Structural Firefighting Helmet

Pacific Helmets NZ Ltd combines safety, comfort, quality, and style in the Pacific F10 MkV. With a DuPont™ Kevlar® and Fibreglass Reinforced Composite Shell, the F10 MkV is incredibly light and, like all Pacific helmets, is designed to last you a lifetime. The optimised shape and low ride height enhances the balanced feel of the helmet to provide you a comfortable fit over long periods of wear.

The Pacific F10 MkV accommodates a wide range of accessories. The design of the F10 MkV has carefully considered the needs of front line firefighters and incorporates unique features such as combining the latest technology in Pacific’s unique co-moulded hinge and liner retaining system. This co-moulded technology ensures the wearers’ head and neck are fully protected from excessive force again emphasizing our goal of delivering the world’s best safety helmets – without compromise.

The F10 MkV was awarded Silver at the New Zealand Best Design Awards in 2015.

Contact your Pacific Helmets representative for more information and to design your F10 MkV.

Recommended Uses

The A7A can be configured for the following uses:

Structural Firefighting

Structural Firefighting
AS/NZS 4067:2012, NFPA 1971:2018, or EN 443:2008

Please note: helmets pictured may be shown with optional features. Please ask your Pacific Helmets representative for more information.

Features of the F10 MkV

Note: Feature Compatibilities

Some features may be either compulsory or unavailable depending on the standard selected. Please ask your Pacific Helmets representative for more information on feature compatibilities.

Included Features

Provides integral strength and excellent penetration protection. This lightweight shell is chemical and UV resistant with inherent heat and flame resistance. Expected service life of 15+ years with proper care and maintenance.

Excellent thermal barrier. Unique crumple zone for superior shock absorption and internal air circulation

Size 52–65cm (downsizing adjustment kits and XL sizes available). Simple operation with a single gloved hand. Comes with comfortable front and rear sweat padding in leather and is easily removable and replaceable for decontamination.

Single handed adjustment at multiple locations for maximum comfort and stability. Leather cheek padding for added comfort (optional).

High speed particle protection. Heat and flame resistant. Anti-scratch and Antifog coated. Optically correct. Clear and Gold Tint available.

Can be easily secured, released, and adjusted with a gloved hand.

Fully modular for easy decontamination and replacement without special tools.

Available in Clear or Smoke Tint. Choose from Manual operation with pull tabs or the One Touch Eye Protector™.

High speed particle protection. Heat and flame resistant. Anti-scratch and Antifog coated. Optically correct. Clear and Gold Tint available.

For mounting either a UK3AA or Adaro Adalit L5 torch (requires torch clip).

Choose from Black Nomex®, Blue, Orange or Yellow FR Cotton.

Allows the helmet to be stored on a hook when not in use.

Premium 3M™ 680 or 3M™ 8887 Reflective Trims available in a range of colours.

Customised branding, rank markings, or other decals are available by request.

Specifications

Sizing

Headband adjusts between 52-65cm. Downsize Kit or Extra Large Headband are also available for smaller or larger head sizes.

Colours Available

Our range of standard colours can be seen here. Custom colours also available, MOQ may apply.

Care

All parts can be removed with simple tools to enable your helmet to be cleaned and maintained. See the User Information Guide for more information.

Warranty

Parts are covered for manufacturing defects and vary from 1-6 years for different helmet components. See the User Information Guide for more information.

Certification

Helmet is certified to the following standards:

AS/NZS 4067:2012 Structural Firefighting
EN443:2008 Structural Firefighting
EN 16471:2014 (CE & UKCA) Wildland Firefighting
EN 16473:2014 (CE & UKCA) Technical Rescue
NFPA 1971:2018 Structural Firefighting

Face Shield is certified to the following standards:

AS/NZS 1337.1:2010
EN 14458:2004
NFPA 1971:2018

Eye Protector is certified to the following standards:

AS/NZS 1337.1:2010
ANSI Z87.1:2020
EN 166:2001
EN 14458:2004
NFPA 1971:2018

Configuration dependent on certification.

Accessories

The F10 MkV is compatible with lighting solutions such as the Underwater Kinetics eLED and Adaro Adalit L5 Torches, and can be fitted with Titan Firecomms with helmet mounted boom microphone and speaker systems. Some accessories may require selected helmet features.
